White Nylon Roll
High-quality PA6 material, tough and durable, ideal for diverse industrial applications.
White nylon coil with premium quality for smooth application.
李华
★★★★★
Technical Parameters
Core Parameters
Material: White nylon (PA6/PA66, Polyamide), halogen-free and eco-friendly.
Color: Natural white; Flame retardancy: UL94 V-2, self-extinguishing.
Standard Dimensions:
Inner diameter: Matches M2～M24 screws (e.g. M3 inner diameter ≈ 3.2mm).
Outer diameter: 5～45mm; Thickness: 0.13～3mm (common sizes: 0.5/1.0/1.5/2.0mm).
Size marking example: M3×6×1 (ID 3mm × OD 6mm × Thickness 1mm).
Physical Properties:
Temperature resistance: -40℃～+120℃ (up to 150℃ for short-term use).
Insulation: Dielectric strength ≥20kV/mm, non-conductive and non-magnetic.
Mechanical: Moderate hardness, high tensile strength, wear-resistant, self-lubricating, shock-absorbent and noise-reducing.
Chemical: Acid & alkali resistant, corrosion resistant, rustproof and oil resistant; suitable for humid and slightly corrosive environments.
Main Applications
1. Electrical Insulation & Short-circuit Prevention
Nylon is non-conductive. It isolates PCB boards from metal enclosures, between multi-layer PCBs, and between components and housings, preventing short circuits, electric leakage and high-voltage breakdown, and improving overall safety and reliability.
2. Spacing & Height Support
It fixes and elevates circuit boards and assemblies to a designated height, reserving routing space and heat dissipation gaps, avoiding structural interference and optimizing internal layout.
3. Fastening & Connection
Used with screws to firmly fix PCBs, modules and panels. It replaces metal studs to reduce conduction risks. Hexagon design allows easy tool tightening and simple installation.
4. Shock Absorption, Heat Insulation & Corrosion Resistance
Nylon features proper elasticity to absorb vibration and protect sensitive components. It also provides heat insulation, acid and alkali resistance, and rust-proof performance. Lightweight and suitable for humid and harsh working environments.
Typical Application Scenarios
Electronic equipment: PCB insulation and support for motherboards, power supplies, routers, switches and consumer electronics.
Electrical control: Insulation and fixing for industrial computers, inverters, relays and instruments.
Automobile & new energy: Insulation and vibration resistance for vehicle electronics and charging pile control boards.
Home appliances & medical devices: Internal isolation and support for air conditioners, washing machines and medical equipment.
General machinery: Light structural support, spacing columns and insulating connectors.
Common Types
By structure: single-pass (one end threaded, one end plain), double-pass (both ends threaded), hexagonal, round and buckle type.
